ISINAC Cylindrical Acoustic Panel

Effective Sound Absorption and Distinctive 3D Design

The ISINAC Cylindrical Acoustic Panel is a professional suspended solution for improving room acoustics and reducing reverberation.

The three-dimensional cylindrical shape allows the creation of distinctive ceiling acoustic compositions, combining high sound absorption performance with modern architectural design.

Improved Acoustics and Comfort

ISINAC Cylindrical Acoustic Panels absorb unwanted sound reflections and contribute to:

reduced reverberation;
improved speech intelligibility;
enhanced acoustic comfort;
reduced unwanted sound reflections.

Design and Application

The panels are made of grey or white mineral foam and are available with ILUCS or IZZER fabric finishes.

A wide range of colours allows individual cylinders to be combined into customised acoustic compositions. ILUCS also offers customisation with a logo, image or specific Pantone colour.

Applications

• Offices
• restaurants
• Hotels
• theatres
• recording studios
• public spaces
• commercial spaces

The right acoustic solution depends on the size, purpose and acoustic characteristics of the space.

Contact us for assistance in selecting the appropriate size, quantity, configuration and suspension method for ISINAC Cylindrical Acoustic Panels and to receive a customised quotation.

  • Technical Specifications

  • Type

    3D cylindrical sound-absorbing acoustic panel

  • Application

    Ceiling

  • Core material

    Grey or white mineral acoustic foam

  • Thicknesses:

    100 / 150 mm

  • Length

    1200 mm

  • Sound absorption range

    100–5000 Hz

  • Fabric finishes

    ILUCS / IZZER

  • Installation

    Suspended

  • Reaction to fire (Euroclass):

    Mineral foam: C-s2,d0
    ILUCS: B-s1,d0
    IZZER: C-s1,d0

  • Standard sizes:

    Ø100 × 1200 mm
    Ø150 × 1200 mm

  • Downloads

    ADH ABSORBATION DATA SHEETIZZER - colors3D HANGING FOAM PANEL3D HANDING PANELILUCS - colors
